| बॉक्स सामग्री: | कार्बन स्टील Q235B | ट्रक ब्रांड: | DONGFENG |
|---|---|---|---|
| ट्रक इंजन: | चाओचाई 120hp | GearBox: | 5 फॉरवर्ड और 1 रिवर्स |
| थका देना: | 7.50R16 | स्टीयरिंग: | एलएचडी, लेफ्ट हैंड ड्राइव, आरएचडी, राइट हैंड ड्राइव |
| Hooklift Capacity: | 3-6 tons | बॉक्स की लंबाई: | 3350 मिमी |
| बॉक्स की चौड़ाई: | 2000 मिमी | बॉक्स की ऊँचाई: | 1150 मिमी |
| Discharing Way: | Rear Dumping | संचरण प्रकार: | मैनुअल, स्वचालित |
| Driving type: | LHD/RHD, 4*2, 8X4/6X4/4X2 | प्रयोग: | गंदी जगह |
| नियंत्रण का तरीका: | तीन-तरफा हाइड्रोलिक नियंत्रण वाल्व | ||
| प्रमुखता देना: | Dongfeng Hydraulic Hook Lifting Truck,4CBM Hydraulic Hook Lifting Truck |
||
1. Chassis of Hook Arm Garbage Truck optional for :Sinotruk howo,dongfeng,isuzu,faw,jac,shacman,camc and so on.
2. Garbage Bin with different size options of Hook Arm Garbage Truck: 4cbm to 12cbm;: Engine 266hp,290hp,336hp,371hp, Fast Gearbox 10 Forward & 2Reverse;
3. Hydraulic Control Loading&Unloading System;
4. Different shapes of Hook Arm Garbage Truck bins such as trapzoid,boat-shape,square shape and so on and divided into above-ground and under-ground type;
5. High-tensile steel chains:imported hydraulic oil cylinder and sealing material;
6. Lifting oil cylinder of Hook Arm Garbage Truck :double oil cylinder under garbage box,so garbage box can be lifted and self-dumped;
7. Double rear landing leg controlled by hydraulic multi-way valve to stablise truck;
8. Best Choice for Garbage collection and transporation Inside City.
Hook lift System Structure
| Dongfeng D7 Furuika Hooklift Garbage Truck | |||
| Type | Hooklift | Overall Size | CLW5090ZXX6 |
| Overall Size | 4780x1900x2190 | Traction | 4x2 |
| Box Volume | 4 cubic meters | Lifting Capacity | 2215kg |
| Vehicle Total Weight | 4495kg | Max Speed | 103 km/h |
| Tare Weight | 1800 kg | Wheel Base | 2600 |
| Loading Weight | 3500kg | Tire | 7.50R16 |
| Passenger Allowed | 3 person | Tire No. | 6 |
| ABS | Yes | Fuel | 16.5, 17.2 |
| Leaf Spring | 8/10+7, 12/12+9 | Fuel Type | Diesel |
| Emission Standard | Euro 2 ~ Euro 6 | Engine | Yuchai |
| Power | 102HP | Displacement | 2360, 2977, 2968 |
Main structure
OTHER TYPES TANK & TRUCK
FACTORY SENCE:
Quick feedback to solve your questions
Professional engineering and production team
Related Accessories and spare parts offered,no future worries
Regular customer after-sale visiting
Free technical staff training and guidance
Reasonable price and good quality
Quick delivery and shipmen
FAQ
Q1: What kinds of container hook lift truck I can order from your company?
A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2: Have you supplied container hook lift truck to any overseas companies?
A: Yes,with need of garbage waste transport,we offered container hook lift trucks to many Africa and south-east Asian countries.
Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. Wuhan is two hours' plane from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
