उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| ब्रांड: | डोंगफेंग, एफएडब्ल्यू, फोटॉन, हाउ, जेएसी, जेएमसी, इसुजु | पहिये का आधार: | 4700 मिमी |
|---|---|---|---|
| कचरा पात्र सामग्री: | Q345B, उच्च तीव्र कार्बन स्टील | Thickness: | 5 mm for both side and buttom container |
| अवयव: | लोड करना, कंप्रेस करना, डिस्चार्ज करना | कैम्पैक्टिंग अनुपात: | 0.6-0.7 टन/सीबीएम |
| ऑपरेटिंग सिस्टम: | एक केबिन में, एक ट्रक के पीछे | गारंटी: | प्रमुख भागों के लिए एक वर्ष |
| ऑपरेशन वीडियो: | हाँ, विकल्प के लिए बहु-भाषा के साथ | तकनीकी समर्थन: | 20 साल का अनुभवी इंजीनियर जरूरत पड़ने पर आपकी मदद करेगा |
| प्रयोग: | घरेलू कचरा परिवहन | प्रतीक चिन्ह: | ग्राहक के अनुरोध के अनुसार |
| प्रमुखता देना: | 14cbm Refuse Collection Truck,210HP Refuse Collection Truck,14cbm Compression Garbage Truck |
||
14cbm Refuse Collection Truck 14m3 Compression Garbage Truck
Specifications of 14CBM Refuse Collection Truck
| Dongfeng 6CBM Compressed Garbage Truck | |||||
| Overall Dimension | 8350×2490×3250 mm | Gross Vehicle Weight |
15800 kg |
||
| Curb Weight | 9850 kg | Loading Weight | 5755 kg | ||
| Wheel Base | 3800 mm | Front / Rear Axle | 5000 kg / 10000kg | ||
| Cabin | Left Hand Driving, 3 Passengers Allowed, with Air Conditioner, Radio | ||||
| Engine | Cummins | ||||
| Engine horsepower | 210HP, EURO II | ||||
| Max Driving Speed | 90 km/h | ||||
| Gear Box | 8 Forward Gear, 1 Reverse Gear, | ||||
| Tire | 9.000R20 (6 pieces with one spare) | ||||
| Garbage Bin | Capacity | 14CBM | |||
| Material | 5mm Carbon Steel for Garbage Bin Body | ||||
| Design | Whole unit with Leakage Proof Design | ||||
| Ways of Loading | Rear Loading with optional Bucket Lifting System | ||||
| Garbage Compact Ratio | 0.6 - 0.7 | ||||
| Control System | One control Panel on the back, One Control system in back of Cabin | ||||
| Working System | 1. Equipped with air-tight dustbin, hydraulic system and operating system. | ||||
| 2. Automatic loading, compressing and discharging, all handled by 1 person | |||||
| 3. Sewage water collection tank to avoid any pollution during handling. | |||||
| 4. Large Pressure, Good Leakage Proof, Convenient Operation | |||||
| Dependable Security | |||||
| 5. Electrical Control Panel for compacting system. | |||||
| 6. Cycling time＜14~18s | |||||
| Remarks | 1. Color is optional | ||||
| 2. Customized LOGO painting as per customer request | |||||
Truck Details:
Diagram
Working Show
Quick feedback to solve your questions
Reasonable price and good quality
Quick delivery and shipment
FAQ
Q1: What kinds of garbage trucks I can order from your company?
A: There are various sizes and types of garbage trucks with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2:: Have you supplied garbage truck to any overseas companies?
A: Yes,with need of garbage waste transport,we offered garbage trucks to many Africa and south-east Asian countries.
