उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| सामग्री: | कार्बन स्टील, | प्रोडक्ट का नाम: | पिछला डम्पर अपशिष्ट पुनर्चक्रण ट्रक, सीलबंद कचरा ट्रक |
|---|---|---|---|
| ड्राइव प्रकार: | 4X2 6पहिए 6 पहिया | ड्राइव मॉडल: | बाएं हाथ की ड्राइव, या आरएचडी |
| लोडिंग क्षमता: | 5 टन, 6 टन, 8 टन, 5टी, 6टी। 7टी, 8टी | ट्रक ब्रांड: | सिनोट्रुक HOWO, डोंगफेंग, शैकमैन, FAW, फोटॉन, जैक |
| टक प्रकार: | अपशिष्ट संग्रहण ट्रक. रीसाइक्लिंग ट्रक से इनकार करें | अन्य उपकरण: | हाइड्रोलिक प्रणाली के साथ, लिफ्टिंग आर्म डम्पर टिपिंग |
| स्थिति: | डोंगफेंग ब्रांड, बिल्कुल नया ट्रक | नियंत्रण प्रणाली: | बहु वाल्व |
| लोडिंग एवं अनलोडिंग: | हाइड्रोलिक तेल सिलेंडर | ||
| प्रमुखता देना: | Rear Dumper Sealed Garbage Compactor Truck,5T Garbage Compactor Truck,Dongfeng 4x2 Rubbish Compactor Truck |
||
HOWO 6x4 20Tons Hydraulic Roll off Pull Arm Hook Lifting Garbage Collection Truck
Product Description
1-- Garbage compactor truck is divided into compactor garbage truck, swing arm garbage truck, hook lift garbage truck, roll on roll off garbage truck,bin lift garbage truck,dumper garbage truck,sealed garbage truck,container garbage truck, rear load garbage truck and so on.
2-- Easy Full Automatic Operation: computer control system for loading and unloading operations.
3-- One Person Operation: Reducing sanitation working, greatly improves the working environment.
4-- Double Operation System: computer control system and manual operation greatly improves the vehicle usage rate.
5-- Capacity: option for 3-20m3 garbage truck.
6-- Steering wheel: both left and right hand drive,meet the needs of different countries
7-- Emission standard: option Euro 1,Euro 2,Euro 3,Euro 4,Euro 5 garbage truck
8-- Truck chassis: option for japanese and chinese brand,such as dongfeng,isuzu,faw,foton,howo,jac,jmc,forland.
Features:
1. Garbage Compactor Truck change the dirty appearance of the city and eliminate the secondary pollution
2. Easy Full Automatic Operation: computer control system for loading and unloading operations.
3. One Person Operation: Reducing sanitation working, greatly improves the working environment.
4. Double Operation System: computer control system and manual operation greatly improves the vehicle usage rate.
product Specification
| Classification | Item | Unit | Parameter |
| Vehicle | Overall dimensions | mm | 5780*2000*2260 |
| Curb weight | kg | 3550 | |
| Traction system | 4×2 | ||
| Max speed | km/h | 95 | |
| Chassis | Number of axles | 2 | |
| Wheel base | mm | 3308 | |
| Tire specification | 7.00R16 | ||
| Number of tires | 6 | ||
| F/R track base | mm | 1040 /1250 | |
| Engine | Engine model | CY4102-C3F | |
| Fuel type | Diesel | ||
| Power | kw | 70 | |
| Engine horse power | hp | 95 | |
| Displacement | ml | 2982 | |
| emission standard | Euro 3 | ||
| Instruction | 1. Garden tanks , the effective volume reaches 90% 2. Equipped with rubbish drum lifting system , the system has dustbin lock structure make sure that loading and unloading safe and reliable. 3. Equipped with hydraulic system and operating system. 4. The feature : high level of automation , reliable working , well sealed , bulk loading , easy control and good environmental protection. |
||
| Color &Painting | According to customer's requirements | ||
Warranty
1. One year free warranty for major 3 components of our trucks: engine, gearbox, axles.
2. We offer video guidance and our engineers will go to customer's country to assist the installation and operation when quantity reaches 20 units.
3. Transportation warranty: our company offers transportation insurance for customer to ensure the products arriving at destination safely.
Products Catalog:
1. LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck /Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
