उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| प्रोडक्ट का नाम: | सिनोट्रक HOWO रोड व्रेकर रिकवरी रेस्क्यू ट्रक | इंजन अश्वशक्ति: | 336 एचपी, 371 एचपी। 420hp |
|---|---|---|---|
| ट्रक ब्रांड: | सिनोट्रुक HOWO, SHACMAN, FAW, FOTON, JAC आदि | ड्राइव मॉडल: | 6x4, 10 पहिये, 8x4, 12 पहिये, |
| ड्राइव प्रकार: | राइट हैंड ड्राइव, या लेफ्ट हैंड ड्राइव। | विध्वंसक प्रकार: | 360 डिग्री रोटेशन. 360 डिग्री घुमाया गया. |
| उपकरण: | हाइड्रोलिक पंप, तेल सिलेंडर | मुख्य भाग: | बूम, उत्थापन, चरखी, लैंडिंग लेग |
| लोडिंग क्षमता: | 30 टन, 40 टन, 50 टन, 60 टन, 70 टन आदि | ||
| प्रमुखता देना: | 360 Degree Rotation Wrecker Tow Truck,420HP Wrecker Tow Truck,HOWO 8X4 Emergency Tow Truck |
||
Sinotruk HOWO 8x4 371hp 50tons 50T Road Wrecker Recovery Towing truck 360 Degree Rotation Wrecker Tow Truck
Product Description:
1. Purpose of Recovery Truck: wrecker/recovery truck/towing truck is used for towing break-down cars or vehicle or bus or trailers on road.With increasing ownership of private cars,wreckers are now widly used by government organization or towing company.
2. Optional brand of Recovery Truck :howo,Dongfeng,Isuzu,JAC,JMC,Foton,Shacman...
3. Spare parts of Recovery Truck : Italy brand multi-way valve and balance valve; Gernamy Roxroth technology hydraulic cylinder and joint; imported sealing element; strengthed checked plate
4. Capacity range of Recovery Truck:3ton, 4ton, 5ton, 6ton, 8ton, 12ton, 16ton, 20ton, 25ton, 31ton, 40ton, 50ton
5. Fifth wheel attachment is optional for towing trailers as follows
HOWO 8X4 371HP 420HP 360 Degree Rotation Rotator Road Recovery Truck Vehicle 50 tons Emergency Wrecker Tow Trucks
| Cabin | Driving type 8x4, Left hand drive | ||||
|
HOWO 76 cab, with air condition and one bed, 70°hydraul`ically tillable to the front as attached photo for ref. |
|||||
| Vehicle Main Dimensions | Overall dimensions (L x W x H) mm | 11460×2500×3270 | |||
| Wheel base (mm) | 1800+4600+1350 | ||||
| Wheel track (front/rear) (mm) | 2022/1830/1830 | ||||
| Approach/Departure angle(°) | 16/18 | ||||
| Weight in KGS | Tare Weight | 24870 | |||
| payload | 30000 | ||||
| Front axles loading capacity | 2x9000 | ||||
| Rear axles loading capacity | 2x16000 | ||||
| Engine | Brand | Sinotruk | |||
| Model | WD615.47 | ||||
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||||
| Horse Power(HP) | 371HP | ||||
| Emission standard | Euro-2 | ||||
| Gearbox | HW19710, 10 Forwards gear & 2 reverse gear | ||||
| Tire | 12R22.5 tubeless tire with one spare | ||||
| Clutch | Reinforced diaphragm clutch, diameter 430 mm | ||||
| Steering | ZF8118 | ||||
| Oil tank | 400L | ||||
| Special Device For Wrecker System for 50tons. | |||||
| Hoisting Organ | Rated under-pulling capacity | 50000 | |||
| Max Under-hoisting Capacity (kg) | 50000 | ||||
| Max Under-hoist length (mm) | 1850 | ||||
| Under hoisting work angle | -10~85° | ||||
|
Lifting Organ
|
Max lifting capacity(kg) | 50000 | |||
| Max lifting high(mm) | 12000 | ||||
| Telescope length(mm) | 6000 | ||||
| Winch | 25000kgs×2 | ||||
| Steel rope | 50M,Φ30 | ||||
| Crane luffing angle | 5°~ 60° | ||||
| Crane rotation angle | 360°All Rotation | ||||
|
Landing Leg |
Distance between front legs(mm) | 7000 | |||
| Distance between rear legs(mm) | 4300 | ||||
Sales Service
① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
