| ट्रक चेसिस: | डोंगफेंग, होवो, इसुजु, शेकमैन, सीएएमसी, फोटॉन | Capacity: | 6tons/6CBM |
|---|---|---|---|
| प्रकार: | पानी की टंकी फायर ट्रक, फोम, सूखा पाउडर फायर ट्रक, बचाव फायर ट्रक | आग पंप: | चीनी ब्रांड |
| अग्निशमन सीमा: | ≥50 मी | मॉनिटर की प्रवाह दर: | 48ली/एस |
| पंप की प्रवाह दर: | 60ली/से | स्टीयरिंग: | एलएचडी या आरएचडी |
| प्रमुखता देना: | Dongfeng Fire Fighting Truck,6000L Water Tank Fire Fighting Truck,4X4 Firefighter Truck |
||
| Main specification | |||||||||
| Product model and name | DONGFENG fire fighting truck | ||||||||
| Gross weight(Kg) | 14000 | Drive type | 4X4 | ||||||
| Payload(Kg) | 5950 | Overall dimension(mm) | 7800×2499 ×3196 | ||||||
| Curb weight(Kg) | 8050 | Cab seats | 5 | ||||||
| Approach/departure angle(°) | 34/17 | Front/rear hang(mm) | 1180/1815 | ||||||
| Axle No. | 2 | Wheelbase(mm) | 4500 | ||||||
| Front Axle/Rear axle load(Kg) | 5000/9000 | Max speed(Km/h) | 90 | ||||||
| Chassis specification | |||||||||
| Chassis model | EQ 1161 | Manufacturer | Dongfeng Motor Co.,Ltd | ||||||
| Brand name | Dongfeng | Tyre No. | 6 | ||||||
| Tyre specification | 10.00-20 | Transmission | 6 forward gear,1 reverse gear | ||||||
| Emission standard | Euro 3 | ||||||||
| Cab | Dongfeng 153 type cabin . Four opening doors and whole flat top with crew cab. And all steel frame welded structure with air condition. With Front winch (capstan) | ||||||||
| Engine model | Engine manufacturer | Displacement(ml) | Power(Kw) | Horsepower(HP) | |||||
| B170-33 | Dongfeng cummins engine co. LTD | 5900 | 125 | 170 | |||||
| Water tank fire fighting truck performance | |||||||||
| Water tank volume(L) | 6000 | ||||||||
| Tank material | Carbon steel material | ||||||||
| Fire monitor |
Fire monitor model PS30, level rotation by 360º, Max elevation +45º, Max angle of depression -15º, Flow rate:30L/S,Range≥50 m/1.0MPa |
||||||||
| Fire pump | Model: CB10/40 Flow rate:40L/S Pressure:1.0MPa | ||||||||
Products Show
Equipment of fire rescue fighter truck
Factory and production of fire rescue fighter truck
FAQ
Q1: What kinds of fire enigne truck I can order from your company?
A: There are various sizes and types of fire enigne truck with different functions,you can contact us and tell your request.We will recommend you suitable product.
Q2:: Have you supplied fire enigne truck to any overseas companies?
A: Yes,with need of government project,we offered fire fighting trucks to many Africa and south-east Asian,south-American countries.
Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory is based in Suizhou city, Hubei province, China. Our overseas marketing office is in Wuhan city,Hubei Province.Wuhan is about two hours' plane and four hours' high speed train from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
