उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| Brand: | ISUZU,Dongfeng,JAC,JMC,forland,foton | इंजन: | इसुज़ु ब्रांड |
|---|---|---|---|
| front leg: | H shape | Rear leg: | H type |
| ऊंचाई: | 18 मीटर, 20 मीटर, 22 मीटर, 18 मीटर, 20 मीटर, 22 मीटर | बाल्टी क्षमता: | 200 किलो |
| Passenger: | 2~3 Person | व्हीलबेस: | 4500/3950 |
| Arm term: | Telescopic type | प्रसव के समय: | 30 दिन |
| उपयोगकर्ता पुस्तिका: | हाँ | गारंटी: | 1 वर्ष |
| प्रतीक चिन्ह: | ग्राहक के अनुरोध के अनुसार | ||
| प्रमुखता देना: | 22m Aerial Work Platform Truck,20m Aerial Work Platform Truck,18m platform lift truck |
||
| Parameter | Overall dimension (Length*width*high) | (mm) | 9500×2500×31500 |
| Total Mass | (kg) | 8500 | |
| Kerb Mass | (kg) | 8050 | |
| Wheel base | (mm) | 4175 | |
| Front/rear tract base | (mm) | 1385/1425 | |
| Approach/rear angle | 27/11 | ||
| Max speed | (km/h) | 95 | |
| Fuel type | diesel | ||
| Engine | Engine type | ISUZU | |
| Displacement standard | EURO 4 | ||
| Chassis | Chassis type | isuzu | |
| Drive system | 4x2 | ||
| Tire type | 8.25-16 | ||
| Number of tire | 6 | ||
| Front/rear axle loading(kg) | 1015/2025 | ||
| passengers | 2+3 | ||
| Cabin | Single, with 2 passengers allowed, with Air conditioner | ||
| Special parameter | Working platform rating loading | (kg) | 200 |
| Working Height | (m) | 22 | |
| Max working radius | (m) | 9.67 | |
| Boom type | three section knuckle arm | ||
| Max hook height | (m) | 9.9 | |
| Loading of hook | (kg) | 800-1000 | |
| Max rotation angle | (°) | 360 |
Diagram for aerial platform truck
