| ब्रांड: | चीन का मशहूर ब्रांड शैकमैन | लोडिंग क्षमता: | 35टन 40टन 45टन 50टन |
|---|---|---|---|
| उठाने का प्रकार: | फ्रंट टिपिंग, मिडिल टिपिंग | तेल सिलेंडर ब्रांड: | अंतर्राष्ट्रीय ब्रांड HYVA या चीनी ब्रांड |
| डम्पर की मोटाई: | साइड 6 मिमी, निचला 8 मिमी या ग्राहक के अनुरोध के अनुसार | डम्पर सामग्री: | उच्च गुणवत्ता Q345B |
| रंग: | सफेद, लाल, पीला या अनुकूलित | इंजन: | 385 एचपी 420 एचपी |
| प्रमुखता देना: | 10 wheel dump truck,heavy equipment dump truck |
||
40ton 8x4 Dump truck 45tons CAMC dump truck front tipping heavy duty tipper truck for sale
Product Description
1) Dump truck brand:SINOTRUK HOWO,CAMC,SHACMAN,JAC,NORTH-BENZ,ISUZU,FOTON...
2) Tipping Model:Front-tipping,middle tipping dump truck,HYVA or Chinese brand hydraulic oil cylinder brand
3) High tensile steel for dumper materia,4mm,6mm,8mm, 10mm oer as per client's request and purpose.
4) Used in construction site for transportation of mineral,stone,sand and so on.
| Condition | New condition/Left hand drive/6x4 | ||
| Chassis | Brand | CAMC | |
| Curb weight(kg) | kg | ||
| Axle loading(Front/Rear)(kg) | 7500/7500/16000/16000 kg | ||
| Wheelbase(mm) | mm | ||
| Dimensions(mm) | mm | ||
| Wheel track (front/rear) (mm) | 2036/1860/1860/1860 mm | ||
| Front/Rear overhang(mm) | 1525/1660 mm | ||
| Approach/Departure angle(°) | 28/18 | ||
| Max. driving speed(km/h) | 85 km/h | ||
| Clutch | Reinforced diaphragm clutch | ||
| Fuel tank volume(L) | 400 L | ||
| Brakes |
Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake |
||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 10pcs with one spare tire | |
| Specifications | 12R22.5 | ||
| Transmission | Manual type, 10 Forwards and 2 reverses | ||
| Cab | It can accommodate three people, With Air conditioner. | ||
| Engine | Brand | CAMC | |
| Fuel type | Diesel | ||
| Power(kw) | 283 kw | ||
| Horsepower(HP) | 385 HP | ||
| Cylinder number | 6 | ||
| Emission standard | Euro 2 | ||
| Upper | Size(mm) | 7000X2300X1200 mm | |
| Max. Loading weight(kg) | 25-40 tons | ||
| Button Thickness(mm) | 8.0 mm | ||
| Side plate Thickness(mm) | 6.0 mm | ||
| Material | Q235 Carbon steel | ||
| Tipping type | Front Tipping | ||
| Oil cylinder brand | China local brand | ||
| Remarks | 1. Color is optional | ||
FAQ
Q1: What kinds of dump trucks I can order from your company?
A: There are various sizes and types of dump trucks,you can contact us and tell your request.We will recommend you suitable product.
Q2:: Have you supplied dump trucks to any overseas companies?
A: Yes,we offered dump trucks to many Africa and south-east Asian,south-American countries.
Q3 What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory is based in Suizhou city, Hubei province, China. Our overseas marketing office is in Wuhan city,Hubei Province.Wuhan is about two hours' plane and four hours' high speed train from Beijing,Shanghai or Guangzhou city,welcome to visit us for factory inspection.
