उत्पाद विवरण:
भुगतान & नौवहन नियमों:
|
| चेसिस ब्रांड: | इसुजु, डोंगफेंग, फोटोन, सिनोट्रुक, जेएसी, आदि। | कैम्पैक्टिंग अनुपात: | 0.8-0.9 टन/एम3 |
|---|---|---|---|
| संक्षिप्तीकरण अनुपात: | ३-४ | संपीड़न चक्र समय: | ≤15 एस |
| कचरा उतारने का समय: | ≤23 एस | हाइड्रोलिक दबाव: | 16MPA |
| कचरा बॉक्स की मोटाई: | साइड 3 मिमी, निचला 4 मिमी, कार्बन स्टील-Q345A | कचरा बॉक्स वॉल्यूम: | 5cbm, 8cbm, 10cbm, 12cbm, 15cbm, 18cbm, 20cbm, आदि। |
| कचरा पेटी क्षमता: | 4टन, 6टन, 8टन, 10टन, 12टन, 15टन, 16टन, आदि। | गंदे पानी की टंकी की मात्रा: | 0.2 सीबीएम |
| हूपर वॉल्यूम: | 0.8 सीबीएम | नियंत्रण का तरीका: | मैनुअल और विद्युत नियंत्रण |
| लोगो और पेंटिंग: | ग्राहक के अनुरोध के अनुसार | प्रसव के समय: | 30 कार्य दिवस |
| गारंटी: | 1 वर्ष | ||
| प्रमुखता देना: | Foton Waste Compactor Truck,Jmc Waste Compactor Truck,10cbm Howo Garbage Compactor Truck |
||
Product Description
1. Making garbage collection simple: change the dirty appearance of the city and eliminate the secondary pollution;
2. High compression ratio and large loading capacity which is 2 times larger than usual garbage truck;
3. Easy Full Automatic Operation: electrical control system for loading and unloading operations.
4. One Person Operation: Reducing sanitation work, greatly improves the working efficiency.
5. Double Operation System: electrical control system and manual operation greatly improves the vehicle usage rate.
Product Specification
| Upper Body Specification | ||
| Compector Box | Box Volume | 10cbm/6Tons |
| Box Capacity | 10Ton | |
| Dirty Water Tank Volume | 0.2CBM | |
| Hopper Volume | 0.8CBM | |
| Compression density | 0.8-0.9T/CBM | |
| Compression ratio | 3-4 | |
| Compression cycle time | ≤15 s | |
| Unload garbage time | ≤23 s | |
| Body Thickness | Side | 3mm, Carbon Steel-Q345A |
| Bottom | 4mm, Carbon Steel-Q345A | |
| The Electromagnetic Valve | UZCT-115/24V, 2sets | |
| Hydraulic Pressure | 16Mpa | |
| Controlling Way | Manual and electrical control | |
| Other Configuration |
|
|
| Options | Tail feed flip frame or flip bucket, PLC one-button control system, etc. | |
Reference Photos
Structure Diagram
Sales Service
1)Pre-sales Service: Communicate with customers, analyze their needs.
2)Sales Service: Provide professional technical solutions, recommend the right models accordingly.
3)After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.
FAQ
Q1: What kinds of garbage truck I can order from your company?
A: We can supply different kinds and sizes garbage trucks as client's request. Basically speaking, we can supply 5CBM to 20CBM compactor garbage truck, hook lift garbage truck, swing arm garbage truck, hanging barrel garbage truck, etc. Pls contact with us for more technical details and discussion.
Q2: What is your production standard of garbage trucks?
A: China GB local standard.
Q3: Can we adopts International brand equipment or accessories for garbage truck?
A: Sure, we already cooperated with many international brand suppliers.
Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.
Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to Wuhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
